- Understanding Git repositories and levels
- Learning how to use Git from the command line
- Configuring and syncing your repository
On GitHub, our software code is organized in repositories, each of which represents different projects or components of projects we're working on. For example, you have been working on one of our repositories, called treehouses.github.io. We would strongly suggest you to look (look, don't touch) at our different repositories on GitHub. These repositories act as a categorizing system for us to organize our code.
You previously forked a repository from treehouses to work on, which means that that a version of the treehouses repository was available on your own GitHub account. You were then able to modify your fork, then send an update to the upstream repository in the form of a pull request.
This is just a summary of the steps that you will need to perform. Keep on reading for a detailed explanation of each step.
- Clone Your GitHub Repository username.github.io
- Clone with HTTPS or Clone with SSH?
- Explanation About Repositories and Syncing Process
- Configure a Remote Repository for Your Fork
- Sync Your Fork
NOTE: You will see some common names used in git (which you can change), such as master: the name of the main branch, upstream: the location where you forked the repository from, and origin: the location you cloned repository from. Both upstream and origin are considered remote. Keep in mind also, a repository may contain many branches.
Now, we will be using GitHub repositories on a command line, which means that there is a separate step to get your GitHub repository on your OS. To be clear, you will be using both the command line and the GitHub user interface, meaning that you need to constantly check to make sure that your version is not behind to avoid merge conflicts. Therefore, open your username.github.io repository on the GitHub user interface and copy the link provided by clicking the "Code" button.
Then, turn to your command prompt and type git clone <repository_url> into the command line. For example git clone https://github.com/EmilyLarkin/EmilyLarkin.github.io.git. Be sure to use the correct URL to clone your repository (you will obviously type your own username). If you cd into your username.github.io you can see different files which you will be working on during your internship.
Both HTTPS(Hypertext Transfer Protocol Secure) and SSH(Secure Shell) URLs identify the same remote repositories but use different protocols to access the codebase. Both HTTPS and SSH to do the same thing, the differences between the two can be examined here.
The previous step created a clone of your repository on your Operating System.
There are now three different Github repository levels:
- treehouses.github.io
- Your username.github.io on GitHub
- Your username.github.io on your OS.
These three levels need to be constantly synced and kept up to date with one another as we will all be contributing to the same upstream repository (treehouses.github.io).
Maintaining projects across multiple Git repositories with multiple team members requires strict adherance to process to avoid conflict.
- Keep your changes small if possible, do not modify more than 100 lines of code at a time if possible
- Keep your fork updated regularly, this will avoid you doing work on an old version of the repository, which could mean your work may not be accepted
There are various ways to sync the repository on your OS and the one on GitHub (username.github.io) with the upstream repository treehouses.github.io.
First, the GitHub help section and the Git website are incredibly helpful in answering your basic questions.
For example, this link explains how to sync a fork with the correct upstream repo, because as you renamed your repository, it does not automatically assume that treehouses.github.io is the source. Instead, it assumes that username.github.io is the source. This means that when you do git diff and git status, it only looks at your username.github.io. You will therefore need to use git fetch upstream, git checkout master, and git merge upstream/master to correctly sync to treehouses.github.io as we will see below.
Once you set up a remote repository, you will need to add the remote repo url to your local git config, and set an upstream branch for your local branches. To explicitly add the remote repository, run the git remote add origin followed with your repository url. In your case, it is going to be git remote add origin https://github.com/username/username.github.io.git.
To be able to fetch updates from the upstream repository, you need to first configure the upstream repository by following these steps:
-
Open your command prompt/terminal and find the correct directory,
cd username.github.io -
List the current configured remote repository for your fork with
git remote -v. This is what it should look like:
$ git remote -v
origin https://github.com/username/username.github.io.git (fetch)
origin https://github.com/username/username.github.io.git (push)
- Specify a new remote upstream repository that will be synced with the fork by using
git remote add upstream <repository>. Our remote upstream repository will be https://github.com/treehouses/treehouses.github.io.git. Do not forget the.gitat the end.
$ git remote add upstream https://github.com/treehouses/treehouses.github.io.git
- Verify if upstream is configured correctly with
git remote -v.
$ git remote -v
origin https://github.com/username/username.github.io.git (fetch)
origin https://github.com/username/username.github.io.git (push)
upstream https://github.com/treehouses/treehouses.github.io.git (fetch)
upstream https://github.com/treehouses/treehouses.github.io.git (push)
NOTE: You may need to check for the remote repository configurations, especially the url location. For this, run the command cat .git/config and the details of the remote repository named origin are defined in the lines after the [remote “origin”] line.
Then, use the command git fetch upstream to fetch branches from the upstream repository (in this case, it is treehouses.github.io). Next, check your fork's master branch with git checkout master. You should see some variation of this response:
EmilyLarkin.github.io $ git fetch upstream
remote: Counting objects: 1, done.
remote: Total 1 (delta 0), reused 1 (delta 0), pack-reused 0
Unpacking objects: 100% (1/1), done.
From https://github.com/treehouses/treehouses.github.io
6940637..5934ec2 master -> upstream/master
EmilyLarkin.github.io $ git checkout master
Already on 'master'
Your branch is up-to-date with 'origin/master'.
NOTE: If there are any errors after git fetch upstream, please check for typos from previous step. If so, use git remote rm upstream and add the repo in upstream again
Then, use git merge upstream/master to merge the open-learning-exchange upstream/master with your local repository. It should look something like this:
EmilyLarkin.github.io $ git merge upstream/master
Updating 1388180..5934ec2
Fast-forward
If you get something like this,
Please enter a commit message to explain
why this merge is necessary, especially
if it merges an updated upstream into a
topic branch. Lines starting with '#'
will be ignored, and an empty message
aborts the commit.
~
~
it means that you are in the Vim text editor. Simply type :wq which stands for write and quit. However, if you want to insert something you can type "i" and Vim goes into edit mode. To exit edit mode just hit "escape".
Now, your repository has been synced to the upstream/master. However, a discrepancy may still exist between your local (and now your origin/master) versus your username.github.io on GitHub. You will now use git diff and git status to check how your local repository compares to your username.github.io repository. Depending on whether you have more or less commits than your username.github.io, you will either use git pull to receive any changes or git push to push updates to your repository. Most likely, as you just synced with the master, you will use git push to push updates to your username.github.io repo.
$ git push origin masterIf you have uncommitted changes (from mixing interface and terminal use of GitHub repositories), then these commands will be aborted until you fix the discrepancy.
Remember, you should repeatedly use the commands git diff and git status to respectively see the difference between your username.github.io and your local repository and then see the status of your repository and the changes you have made. Once again, you need to sync your repository with the correct master first, otherwise you will not see the correct git diff and git status. git diff and git status only look between your local and username.github.io repos, not your upstream repo.
Below is an example of git diff command showing difference in the file of local and remote repository.
$ git diff
diff --git a/<file name>.md b/<file name>.md
index bf400c0..fc7380b 100644
--- a/<file name>.md
+++ b/<file name>.md
@@ -1,5 +1 @@
What is this?What does diff --git a/<file name>.md b/<file name>.md mean?
Answer: Our diff compares two items with each other: item A and item B. In most cases, A and B will be the same file, but in different versions. To make clear what is actually compared, a diff output always starts by declaring which files are represented by "A" and "B".
What does --- a/<file name>.md and +++ b/<file name>.md mean?
Answer: Further down in the output, the actual changes will be marked as coming from A or B. In order to tell them apart, A and B are each assigned a symbol: for version A, this is a minus ("-") sign and for version B, a plus ("+") sign is used.
This process needs to be repeated whenever you begin to work, to make sure that you are always up to date. If there are discrepancies, it will mess up the code and you could potentially lose your saved changes, because it was not updated properly. We will provide more information on editing and saving changes in the next tutorial.
Generally, this is what the structure of your workflow will look like:
Use the following commands in your command line, but refer back to the descriptions above if there are any errors or further questions about why you are using them:
- Open your command prompt/terminal and find the correct directory
- Copy the HTTPS or SSH link from your repository on the GitHub site
- On the command line, type
git clone *paste your HTTPS or SSH link here*
- The upstream (treehouses.github.io)
- Your username.github.io on GitHub
- Your username.github.io on your OS.
These need to be synced and checked constantly. The upstream repository is the one we are contributing to.
cd username.github.iogit remote -vsee above to make sure you are pushing and fetching to your own repository on GitHub as the origingit remote add upstream https://github.com/treehouses/treehouses.github.io.gitgit remote -vorigins should remain the same, but you should also be fetching and pushing to OLE as the upstream now
git fetch upstream- to fetch branches from the upstream repository (more info)git checkout master- to checkout themasterbranch (more info)git show-branch- to see branches and the changes made in them (more info)git merge upstream/master- You repository should now be synced to upstream/master (more info)
git diff- for comparing different versions of the same file (more info)git status- to view the changes made in the branch, whether the branch is up-to-date with master (more info)git pull- to sync the local repository with the remote repository (more info)git push- to push the updates that you made to the local repositories to the GitHub repositories (more info)
NOTE: Developers should always sync their fork and make sure their repositories are up to date with GitHub every time they begin to work. This way we as a team can minimize data loss, and can save you some time.
NOTE: While rebasing and merging are similar, there is a difference between them. Merging takes all changes in one branch and merges onto another branch in one commit. Rebasing moves the branch's starting point to another place. For example, if you rebased your branch to the master branch, then your branch now incorporates all the changes made in the master, and every time master is changed, your branch is changed as well. In contrast, merging is a one-time change.
For more info on differences of merging vs. rebasing (and when to use which one), check this out
If you would like to understand how syncing with the fork works, here is a useful video
Configure a remote for fork - You can sync changes made in the original repository with a fork. Sync fork - Sync a fork of a repository to keep it up-to-date with the upstream repository. GitHub tutorial - An Introduction to Git and Github for beginners from Hubspot. GitHub's Git Tutorial - An interactive tutorial to learn GitHub in the browser. Git-it Workshop - Runs in your terminal to work and provides a hands-on approach to learn Git and GitHub repositories. Git help - An encyclopedia of useful git workflows and terminology explanations. Git GUIs - A list of Git Graphical User Interfaces and what platforms they work for. Other helpful links and videos
